Important: Transhandler only works via WiFi or LAN, not GPRS!
Model: 6210
- Click on the up arrow, select and enter configuration.
- Enter the admin password. (last 4 digits of the serial number)
- Go down in the menu, until number 7: ECR protocol. Enter it with the enter button and select None ECR.
- By doing the previous step, you will automatically be taken back to the configuration menu. Move down one and enter 8: Transaction handler.
- Here are the different points to fill in:
- Server URL name: new-th.loyaltek.com
- Server Port: 5000
- Server SSL: select TLSv12
- Polling enabled: select Enabled
- Transhandler is now operational.
Model: 8210
- Click on Menu and enter configuration.
- Enter the admin password. (last 4 digits of the serial number)
- Go down in the menu, until number 7: ECR protocol. Enter it with the enter button and select None ECR.
- By doing the previous step, you will automatically be taken back to the configuration menu. Move down one and enter 8: Transaction handler.
- Here are the different points to fill in:
- Server URL name: new-th.loyaltek.com
- Server Port: 5000
- Server SSL: select TLSv12
- Polling enabled: select Enabled
- Transhandler is now operational.
